Thermal Master THOR-002: Advanced Handheld Thermal Imaging Uncompromised Thermal Resolution Redefining portable infrared technology, the THOR-002 delivers exceptional thermal resolution for surveillance, search operations, and industrial diagnostics. Its compact ergonomic design enables rapid deployment while detecting thermal anomalies in complete darkness, fog, or challenging terrain. High-Resolution Imaging System Featuring dual optical systems, this imager integrates a 2MP visible light camera with a 3.5″ 640×480 IPS display for outstanding clarity. Moreover, the 60Hz refresh rate and ultra-fine 40mK sensitivity accelerate inspections. Through innovative X³ Super Resolution, native 256×192 imagery scales to 512×384, revealing critical details in HVAC, electrical, and mechanical systems. IR-Fuse™ Dual-Spectrum Technology Equipped with IR‑Fuse™, the camera merges visible and infrared spectrums for intuitive fault detection. Consequently, its dual-light fusion (PIP) functionality pinpoints issues efficiently within complex environments. Smart Connectivity Suite For seamless workflow integration, USB and WiFi enable real-time image transmission to PCs and mobile devices. Additionally, bundled PC software provides post-inspection calibration of emissivity, distance, and ambient temperature parameters. Extended Operational Capabilities Powering extended field operations, the 5000mAh battery delivers 10.5 continuous hours. Complementary 18W fast charging further ensures minimal downtime between missions. Precision Measurement Tools Six-point temperature scanning with customizable temperature bars enables targeted analysis. Simultaneously, the laser targeting system accelerates inspections by up to 100%, while the noise-reducing microphone captures clear voice annotations. Enhanced Thermal Sensitivity Critical temperature variations measuring 0.04°C become visible through the Razor™ algorithm and IQ+ precision technology. Furthermore, X³ IR™ resolution guarantees diagnostic accuracy across all environments. Ruggedised Field Performance Engineered for demanding conditions, the reinforced ABS housing and alloy base withstand 2-meter drops. The quick-shield lens protection system further ensures reliability during industrial or outdoor deployments. Learn More： Thermal Master
Brand: Thermal Master
SKU: Thor 002
Category: Camera
Price: EUR 399.99
Key Features
- thermal master
- camera
- thermal
- thermal imaging camera
- thor 002
- thor001: ±1.5℃ or ±1.5% of the reading thor002: ±2℃ or ±2% of the reading
Specifications
- Brand: Thermal Master
- SKU: Thor 002
- Model: Thor 002
- Temperature Range: THOR001: ±1.5℃ or ±1.5% of the reading THOR002: ±2℃ or ±2% of the reading
- IR Resolution: 256×192
- Super IR Resolution: 512×384
- Macro Lens: Yes
- Lens Focal Length: 4.3mm
- Digital Zoom: 2/4×
- Display: 3.5 inch IPS（640x480）
- Spot Meter: Center spot/Max/Min/6 Custom Spots/Temperature difference
- NETD/Thermal Sensitivity: ＜35mk
- Image Mode: Fusion, IR（default), PIP, Visual
- Digital Camera: 2MP
- Wireless: Yes
- PC-based Analysis Software: Supports 13 languages (English by default)
- APP: Athermalized Prime Lens
- Laser Indicator: Yes
- Microphone: Yes
- Flash Shield: Lens cap for protection
- Alloy Metal Base: Yes
- IQ+: Yes
- Razor X: Yes
- Image Frequency: 25Hz
- FOV: 40°×30°
- IFOV: 2.79mrad
- Pixel Pitch: 12μm
- Focus Mode: Fixed focus
- Min Focus Distance: 8cm
- Screen Refresh Rate: 60Hz
- Fast Charge: 18W
- Battery: 5000mAh rechargeable lithium battery
- Charging Time: 4h
- Operating Time: 8h
